Model A

1200

850

2350

Model B

1500

850

2350

Model C

1800

850

2350

Customized available

Work top (Option)

made of 8mm white PP board ( epoxy resin laminate, solid chemical resistant laminate and ceramic panel are optional).

Inner shell

made of 8mm white PP board; with water tap, air tap is optional; wind deflector on the backboard; lamp and air collection parts on the top.

Air deflector

made of 8mm white PP board, on the backside and top of chamber, make sure air flow out equably.

Base cabinet

made of 8mm white PP board which has excellent anti-corrosion performance, with seamless welding make sure a strong compact structure and tightness.

View window

vertical sliding window, can be set on any position; 5mm tempered glass with clear view.

Air collection hood

cone shape collecting hood made of white PP board.

Lamp

fluorescent lamp or LED lamp.

Control plate

LCD control plate, with control buttons include power switch, lighting, draught fan and indicator lights, equipment’s running conditions can be easily monitored on the control plate.

Handle/Hinge/Socket

PP handle/PP hinge/AC 220V socket.

Water service parts

one-piece form PP sink, acid and alkali resistant, with filtering and stink-block function.

Air tap(optional)

remote control available.

Exhaust System (optional)

Air speed: fume hood air speed 0.4m/s~0.7m/s.

Noise: running noise should be below 65dB.

Draught fan: centrifugal fans or other fans are optional.
