Steel Fume Hood
Fume Cupboard
Steel Fume Hood, Laboratory Fume Cupboard
- Standard Size:
Model Optional | Length (mm) | Width (mm) | Height (mm)
|
Model A | 1200 | 850 | 2350 |
Model B | 1500 | 850 | 2350 |
Model C | 1800 | 850 | 2350 |
*1. Above are standard size, customized available.
2. Draught fan and pipeline are based on the installation site layout, excluded in the fume hood price.
2.Description:
Framework | made of 1.0mm or 1.2mm steel, with electrolytic degreasing, pickling and phosphating, then electrostatic spraying with Akzo Nobel professional epoxy resin powder, coating thickness 0.07~0.09mm, has good performance of acid and alkali resistance and anti-corrosion. |
Work top (Option) | expoxy resin. Chemical resistant board ceramic board are optional. |
Inner lining: | made of laboratory professional phenolic compact laminate. Ceremic and other materials are optional. |
Air deflector: | made of laboratory professional phenolic compact laminate. Ceremic and other materials are optional. |
Base cabinet: | made of 1.0mm or 1.2mm steel, with electrolytic degreasing, pickling and phosphating, then electrostatic spraying with Akzo Nobel professional epoxy resin powder, coating thickness 0.07~0.09mm, has good performance of acid and alkali resistance and anti-corrosion. |
Glass window: | 5mm /6mm tempered glass window can stop any place in the moving range. |
Control plate: | LCD control plate, with control buttons include power switch, lighting, draught fan and indicator lights, equipment’s running conditions can be easily monitored on the control plate. |
Water service parts: | PP sink, water faucet are optional. |
fan | Draught fan and air duct are optional. |
